Factory Lead Time

12 Weeks

Contact Plating

Nickel, Tin

Mount

Cable, Free Hanging

Mounting Type

Free Hanging (In-Line)

Housing Material

Plastic

Body Material

Copper Alloy

Contact Material - Plating

Nickel

Contact Materials

Brass

Packaging

Bulk

Series

LITTEL-PLUG® 480

Published

2008

Part Status

Active

Number of Terminations

3

Termination

Solder Eyelet(s)

Connector Type

Phone Plug

Color

Black

Gender

Male

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Option

GENERAL PURPOSE

Orientation

Straight

Shielding

Unshielded

Number of Ports

1

Number of Poles

3

Number of Positions/Contacts

3 Conductors, 3 Contacts

Includes

3 pcs - 1 Connector, 1 Handle, 1 Insulator Tube

Internal Switch(s)

Does Not Contain Switch

Body Color

Silver, Black

Industry Recognized Mating Diameter

6.35mm (0.250, 1/4) - Headphone

Actual Diameter

0.250 (6.35mm)

Signal Lines

Stereo (3 Conductor, TRS)

Mating Length/Depth

1.140 28.90mm

Features

Cover, Internal Interlock

Length

73.91mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
