Mount

Panel

Mounting Type

Panel Mount

Housing Material

Polybutylene Terephthalate (PBT), Glass Filled

Body Material

Copper Alloy

Contact Material - Plating

Nickel

Contact Finish Mating

NOT SPECIFIED

Contact Materials

Copper Alloy

Voltage Rated

34VAC/DC

Operating Temperature

-20°C~70°C

Packaging

Bulk

Series

SJ

Published

2006

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

Not Applicable

Termination

Solder Eyelet(s)

Connector Type

Phone Jack

Color

Black

Gender

Female

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Option

GENERAL PURPOSE

Shielding

Unshielded

Current Rating

1A

Configuration

1X1 VERTICAL

Number of Ports

1

Number of Poles

4

Number of Positions/Contacts

4 Conductors, 4 Contacts

Includes

2 pcs - 1 Connector, 1 Nut

Internal Switch(s)

Does Not Contain Switch

Body Color

Silver, Black

Panel Hole Size

0.276 7.00mm

Industry Recognized Mating Diameter

3.50mm (0.141, 1/8, Mini Plug) - Headphone

Actual Diameter

0.142 (3.60mm)

Signal Lines

Stereo (4 Conductor, TRRS)

Features

Mounting Hardware

Diameter

3.5mm

RoHS Status

RoHS Compliant

Lead Free

Lead Free
