Factory Lead Time

12 Weeks

Mounting Type

Free Hanging (In-Line)

Housing Material

Acrylonitrile Butadiene Styrene (ABS)

Body Material

Brass

Contact Material - Plating

Nickel

Contact Materials

Brass

Voltage Rated

12VDC

Operating Temperature

-25°C~70°C

Packaging

Bulk

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Termination

Solder

Connector Type

Phone Plug

Gender

Male

Current Rating (Amps)

1A

Shielding

Unshielded

Insulation Color

Black

Cable Opening

0.217 (5.50mm)

Number of Positions/Contacts

2 Conductors, 2 Contacts

Includes

2 pcs - 1 Connector, 1 Cover

Internal Switch(s)

Does Not Contain Switch

Body Color

Silver, Black

Industry Recognized Mating Diameter

3.50mm (0.141, 1/8, Mini Plug) - Headphone

Actual Diameter

0.126 (3.20mm)

Signal Lines

Mono

Mating Length/Depth

0.551 14.00mm

Features

Cover

RoHS Status

RoHS Compliant
