Factory Lead Time

12 Weeks

Mount

Cable, Free Hanging

Mounting Type

Free Hanging (In-Line)

Package / Case

Metal

Housing Material

Copper Alloy

Body Material

Copper Alloy

Contact Material - Plating

Nickel

Contact Finish Mating

NOT SPECIFIED

Contact Materials

Copper Alloy

Packaging

Bulk

JESD-609 Code

e3

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Number of Terminations

2

Termination

Screw

Connector Type

Phone Plug

Gender

Male

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Option

GENERAL PURPOSE

Orientation

Straight

Shielding

Shielded

Current Rating

10A

Number of Ports

1

Cable Length

84.9mm

Number of Poles

2

Throw Configuration

SPST

Cable Opening

0.250 (6.35mm)

Contact Current Rating

10A

Number of Positions/Contacts

2 Conductors, 2 Contacts

Includes

5 pcs - 1 Connector, 1 Handle, 1 Insulator Tube, 2 Screws

Internal Switch(s)

Does Not Contain Switch

Body Color

Silver

Industry Recognized Mating Diameter

6.35mm (0.250, 1/4) - Headphone

Actual Diameter

0.250 (6.35mm)

Signal Lines

Mono

Mating Length/Depth

1.188 30.20mm

Length

79.4mm

Width

14.6mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
