Mount

Through Hole

Mounting Type

Through Hole

Package / Case

25-Flexiwatt (Formed Leads)

Number of Pins

25

Packaging

Tube

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

25

ECCN Code

EAR99

Type

Class AB

Terminal Finish

Tin (Sn)

Max Operating Temperature

150°C

Min Operating Temperature

-55°C

HTS Code

8542.33.00.01

Max Power Dissipation

80W

Voltage - Supply

8V~18V

Terminal Position

ZIG-ZAG

Number of Functions

1

Terminal Pitch

1mm

Base Part Number

TDA7383

Pin Count

25

Output Voltage

200mV

Output Type

4-Channel (Quad)

Supply Voltage-Max (Vsup)

14.4V

Supply Voltage-Min (Vsup)

14.4V

Number of Channels

4

Nominal Supply Current

5.5A

Power Dissipation

80W

Output Power

35W

Supply Type

Single

Bandwidth

75 kHz

Voltage Gain

32dB

Power Supply Rejection Ratio (PSRR)

65dB

Gain

32 dB

Max Output Power

35W

Max Output Power x Channels @ Load

35W x 4 @ 4 Ω

Harmonic Distortion

10%

Features

Mute, Short-Circuit and Thermal Protection, Standby

Length

29.23mm

Height Seated (Max)

19.37mm

Width

4.5mm

Radiation Hardening

No

RoHS Status

ROHS3 Compliant
