Mount

Through Hole

Mounting Type

Through Hole

Package / Case

Clipwatt-11 (Vertical, Bent and Staggered Leads)

Number of Pins

11

Operating Temperature

0°C~70°C TA

Packaging

Tube

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

11

ECCN Code

EAR99

Type

Class AB

Terminal Finish

Matte Tin (Sn)

HTS Code

8542.33.00.01

Max Power Dissipation

25W

Voltage - Supply

10V~32V

Terminal Position

ZIG-ZAG

Peak Reflow Temperature (Cel)

250

Number of Functions

1

Terminal Pitch

1.7mm

Base Part Number

TDA7253

Pin Count

11

Output Type

1-Channel (Mono)

Operating Supply Voltage

28V

Supply Voltage-Max (Vsup)

32V

Supply Voltage-Min (Vsup)

10V

Number of Channels

1

Nominal Supply Current

2.5A

Power Dissipation

25W

Output Power

10W

Supply Type

Single

Bandwidth

80 kHz

Power Supply Rejection Ratio (PSRR)

60dB

Gain

30 dB

Max Output Power

10W

Max Output Power x Channels @ Load

10W x 1 @ 8 Ω

Harmonic Distortion

10%

Features

Mute, Short-Circuit and Thermal Protection

Radiation Hardening

No

RoHS Status

ROHS3 Compliant
