Lifecycle Status

OBSOLETE (Last Updated: 1 month ago)

Surface Mount

NO

Package / Case

6-DIP Module

Mounting Type

Through Hole

Number of Pins

11

Voltage - Input (Nom)

5V

Published

2006

Series

PSS (6W)

Operating Temperature

-40°C~85°C With Derating

Size / Dimension

1.12Lx0.80W x 0.31 H 28.4mmx20.3mmx8.0mm

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

7

ECCN Code

EAR99

Type

Isolated Module

Applications

ITE (Commercial)

Additional Feature

SEATED HGT-NOM

Power Rating

6W

Terminal Position

DUAL

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Depth

20.5mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-XDMA-T7

Number of Outputs

1

Efficiency

84%

Voltage - Input (Max)

9V

Voltage - Input (Min)

4.5V

Trim/Adjustable Output

YES

Current - Output

500mA

Output Power

6W

Voltage - Output

12V

Current - Output 1

500mA

Total Power Output-Max

6W

Isolation

Isolated

Features

Remote On/Off, OCP

Length

28.5mm

Height

7.874mm

RoHS Status

RoHS Compliant
