Lifecycle Status

OBSOLETE (Last Updated: 1 month ago)

Surface Mount

NO

Mounting Type

Through Hole

Package / Case

6-DIP Module

Number of Pins

11

Voltage - Input (Nom)

5V

Published

2006

Operating Temperature

-40°C~85°C With Derating

Series

PSS (3W)

Size / Dimension

1.02Lx0.63W x 0.31 H 25.9mmx16.0mmx8.0mm

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

7

ECCN Code

EAR99

Type

Isolated Module

Applications

ITE (Commercial)

Additional Feature

SEATED HGT-NOM

Power Rating

3W

Terminal Position

DUAL

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Depth

16mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-XDMA-T7

Number of Outputs

1

Efficiency

84%

Voltage - Input (Max)

9V

Voltage - Input (Min)

4.5V

Trim/Adjustable Output

YES

Current - Output

250mA

Output Power

3W

Voltage - Output

12V

Current - Output 1

250mA

Total Power Output-Max

3W

Isolation

Isolated

Features

Remote On/Off, OCP

Length

26mm

Height

7.874mm

RoHS Status

RoHS Compliant
