Lifecycle Status

OBSOLETE (Last Updated: 2 months ago)

Mounting Type

Through Hole

Package / Case

6-DIP Module

Surface Mount

NO

Number of Pins

11

Operating Temperature

-40°C~85°C With Derating

Series

PSS (10W)

Published

2006

Size / Dimension

1.59Lx0.87W x 0.31 H 40.4mmx22.1mmx8.0mm

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

7

ECCN Code

EAR99

Type

Isolated Module

Applications

ITE (Commercial)

Power (Watts)

12W

Additional Feature

SEATED HGT-NOM

Power Rating

12W

Terminal Position

DUAL

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-XDMA-T7

Number of Outputs

1

Efficiency

84%

Voltage - Input (Max)

76V

Output Voltage

12V

Voltage - Input (Min)

36V

Input Voltage-Nom

48V

Trim/Adjustable Output

YES

Output Current

1A

Output Power

10W

Current - Output 1

1A

Features

Remote On/Off, OCP

Height

7.874mm

Length

40.5mm

Width

22mm

RoHS Status

RoHS Compliant
