Factory Lead Time

15 Weeks

Mounting Type

Through Hole

Package / Case

Module

Surface Mount

NO

Operating Temperature

-20°C~85°C

Packaging

Bulk

Series

PH-F (300W)

Published

2014

Size / Dimension

5.75Lx3.39W x 0.50 H 146.0mmx86.0mmx12.7mm

Pbfree Code

no

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

ECCN Code

EAR99

Type

Isolated Module

Applications

ITE (Commercial)

Power (Watts)

300W

Terminal Position

UNSPECIFIED

Terminal Form

UNSPECIFIED

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Reach Compliance Code

compliant

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-XXFM-X

Number of Outputs

1

Qualification Status

Not Qualified

Voltage - Isolation

3kV

Voltage - Input (Max)

400V

Output Voltage

12V

Voltage - Input (Min)

200V

Input Voltage-Nom

280V

Trim/Adjustable Output

YES

Control Features

Enable, Active Low

Total Power Output-Max

300W

Features

Remote On/Off, OCP, OVP

RoHS Status

RoHS Compliant
