Mount

Through Hole

Mounting Type

Through Hole

Package / Case

Full Brick

Operating Temperature

-10°C~85°C

Packaging

Bulk

Series

VI-200™ (50W)

Published

2013

Size / Dimension

4.60Lx1.80W x 0.52 H 116.8mmx45.7mmx13.2mm

JESD-609 Code

e0

Pbfree Code

no

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Number of Terminations

9

ECCN Code

EAR99

Type

Isolated Module

Terminal Finish

TIN LEAD OVER COPPER

Applications

ITE (Commercial)

Power (Watts)

50W

Max Power Dissipation

50W

Terminal Position

DUAL

Terminal Form

PIN/PEG

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-XDMA-P9

Number of Outputs

1

Qualification Status

Not Qualified

Efficiency

88%

Voltage - Isolation

3kV

Voltage - Input (Max)

160V

Output Voltage

5.2V

Max Output Current

9.62A

Voltage - Input (Min)

66V

Input Voltage-Nom

110V

Trim/Adjustable Output

YES

Features

OCP, OTP, OVP, SCP

Height

13.208mm

RoHS Status

Non-RoHS Compliant
