Factory Lead Time

12 Weeks

Mount

Bulkhead, Panel, Rear Side Nut

Mounting Type

Panel Mount

Mounting Feature

Bulkhead - Rear Side Nut

Shell Material

Metal

Operating Temperature

-40°C~100°C

Packaging

Bulk

Series

Amphe - PPM® Sealed

Published

2006

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Termination

Solder Cup

Connector Type

Receptacle, Male Pins

Number of Positions

12

Color

Silver

Applications

Communication Systems, Instrumentation, Medical, Testing Equipment

Gender

Receptacle

HTS Code

8536.69.40.20

Fastening Type

Push-Pull

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

YES

Filter Feature

NO

Mixed Contacts

NO

Current Rating (Amps)

25A

Total Number of Contacts

12

Ingress Protection

IP67 - Dust Tight, Waterproof

Reach Compliance Code

unknown

Current Rating

5A

Shell Finish

Nickel

Shell Size - Insert

E

Contact Gender

Male

Empty Shell

NO

Backshell Type

SOLID

Coupling Type

SNAP

Features

Backshell

Material Flammability Rating

UL94 V-0

RoHS Status

RoHS Compliant

Lead Free

Lead Free

Ratings

Dust Tight, IP67, Waterproof
