Factory Lead Time

12 Weeks

Mounting Type

Panel Mount

Mount

Flanges, Panel

Mounting Feature

Flange

Shell Material

Metal

Published

2011

Series

Amphe - PPM® Sealed

Packaging

Bulk

Operating Temperature

-40°C~100°C

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Termination

Solder Cup

Connector Type

Receptacle, Female Sockets

Number of Positions

3

Color

Silver

Applications

Communication Systems, Instrumentation, Medical, Testing Equipment

Gender

Receptacle

Additional Feature

STANDARD: IEC 61984, UL 94V-0

Fastening Type

Push-Pull

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

YES

Filter Feature

NO

Mixed Contacts

NO

Option

GENERAL PURPOSE

Current Rating (Amps)

5A

Total Number of Contacts

3

Ingress Protection

IP67 - Dust Tight, Waterproof

Reach Compliance Code

unknown

Current Rating

25A

Shell Finish

Nickel

Shell Size - Insert

F

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Contact Gender

Female

Empty Shell

NO

Backshell Type

SOLID

Coupling Type

SNAP

Features

Dust Cap

RoHS Status

RoHS Compliant

Material Flammability Rating

UL94 V-0

Lead Free

Lead Free

Ratings

Dust Tight, IP67, Waterproof
