Factory Lead Time

8 Weeks

Mount

Free Hanging

Mounting Type

Free Hanging (In-Line)

Shell Material

Zinc Alloy

Insert Material

Thermoplastic

Backshell Material, Plating

Zinc Alloy, Nickel

Contact Finish Mating

Silver

Contact Materials

Copper Alloy

Insulation Materials

Plastic

Voltage Rated

125VAC

Packaging

Bulk

Series

Q-G® AAA

Published

2007

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Termination

Solder Cup

ECCN Code

EAR99

Connector Type

Receptacle, Male Pins

Number of Positions

4

Applications

Audio, Industrial, Instrumentation, Medical

Gender

Male

Fastening Type

Latch Lock

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Option

GENERAL PURPOSE

Orientation

Keyed

Shielding

Shielded

Reach Compliance Code

not_compliant

Current Rating

10A

Shell Finish

Nickel

Shell Size - Insert

XLR

Max Current Rating

10A

Number of Ports

1

Number of Poles

4

Cable Opening

0.100 ~ 0.220 (2.54mm ~ 5.59mm)

Features

Backshell, Cable Clamp, Ground, Strain Relief

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
