Factory Lead Time

12 Weeks

Package / Case

Metal

Mounting Type

Free Hanging (In-Line)

Mount

Cable, Free Hanging

Shell Material

Zinc Alloy

Insert Material

Thermoplastic

Backshell Material, Plating

Zinc, Chrome

Contact Finish Mating

Silver

Contact Materials

Copper Alloy

Voltage Rated

125VAC

Insulation Materials

Plastic

Published

2003

Series

Q-G® AAA

Packaging

Bulk

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Termination

Solder Cup

ECCN Code

EAR99

Connector Type

Plug, Female Sockets

Number of Positions

3

Color

Black

Applications

Audio, Industrial, Instrumentation, Medical

Gender

Female

Fastening Type

Latch Lock

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Option

GENERAL PURPOSE

Orientation

Keyed

Shielding

Shielded

Reach Compliance Code

not_compliant

Current Rating

15A

Shell Finish

Chrome

Shell Size - Insert

XLR

Max Current Rating

15A

Number of Ports

1

Number of Poles

3

Cable Opening

0.100 ~ 0.220 (2.54mm ~ 5.59mm)

Features

Backshell, Cable Clamp, Ground, Strain Relief

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
