Factory Lead Time

4 Weeks

Mount

Cable, Free Hanging

Mounting Type

Free Hanging (In-Line)

Shell Material

Zinc Die Cast

Housing Material

PBT

Weight

52.599989g

Insert Material

Polyamide (PA66), Nylon 6/6 and Polyurethane (PUR)

Backshell Material, Plating

Polybutylene Terephthalate (PBT)

Contact Finish Mating

Gold

Contact Materials

Copper Zinc

Voltage Rated

300V

Operating Temperature

-25°C~85°C

Packaging

Bulk

Series

SACC

Published

2011

JESD-609 Code

e4

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Termination

Screw

Connector Type

Plug, Male Pins

Number of Positions

4

Color

Black, Silver

Fastening Type

Threaded

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Filter Feature

NO

Mixed Contacts

NO

Total Number of Contacts

4

Orientation

A

Ingress Protection

IP67 - Dust Tight, Waterproof

Current Rating

9A

Shell Finish

Nickel

Shell Size - Insert

7/8-4

Contact Gender

Male

Empty Shell

NO

Backshell Type

SOLID

Cable Opening

0.394 ~ 0.472 (10.00mm ~ 12.00mm)

Features

Backshell

Material Flammability Rating

UL94 HB

RoHS Status

RoHS Compliant

Lead Free

Lead Free

Ratings

Dust Tight, IP67, Waterproof
