Factory Lead Time

13 Weeks

Mounting Type

Through Hole

Package / Case

8-SIP Module, 7 Leads

Surface Mount

NO

Operating Temperature

-40°C~85°C With Derating

Series

TMR 3 (3W)

Published

2007

Size / Dimension

0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Number of Terminations

7

ECCN Code

EAR99

Type

Isolated Module

Terminal Finish

Matte Tin (Sn) - with Nickel (Ni) barrier

Applications

ITE (Commercial)

Power (Watts)

2.3W

Terminal Position

SINGLE

Terminal Form

PIN/PEG

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Terminal Pitch

2.54mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Pin Count

8/7

JESD-30 Code

R-XSMA-P7

Number of Outputs

1

Qualification Status

Not Qualified

Efficiency

74%

Voltage - Isolation

1.6kV

Voltage - Input (Max)

75V

Output Voltage

3.3V

Voltage - Input (Min)

36V

Input Voltage-Nom

48V

Trim/Adjustable Output

NO

Features

Remote On/Off, SCP

Width

9.2mm

RoHS Status

ROHS3 Compliant
