Factory Lead Time

9 Weeks

Package / Case

7-SIP Module, 5 Leads

Mounting Type

Through Hole

Number of Pins

7/5

Weight

2.8g

Power Dissipation (Max)

1W

Power - Output (Max)

1W

Voltage - Input (Nom)

5V

Series

ECONOLINE RY (1W)

Packaging

Tube

Operating Temperature

-40°C~70°C

Size / Dimension

0.77Lx0.28W x 0.40 H 19.7mmx7.1mmx10.2mm

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

5

ECCN Code

EAR99

Type

Isolated Module

Applications

ITE (Commercial)

Power Rating

1W

Terminal Position

SINGLE

Terminal Form

PIN/PEG

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Terminal Pitch

2.54mm

Depth

19.65mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-XSMA-P5

Number of Outputs

1

Qualification Status

Not Qualified

Efficiency

66%

Voltage - Isolation

1kV

Voltage - Input (Max)

5.25V

Trim/Adjustable Output

YES

Current - Output (Max)

84mA

Current - Output

84mA

Output Power

1W

Max Output Voltage

12V

Voltage - Output

12V

Nominal Input Voltage

5V

Isolation

Isolated

Nominal Output Voltage

12V

Max Input Voltage (DC)

5V

Min Input Voltage (DC)

4.75V

Features

SCP

Height

10.2mm

Width

7.05mm

RoHS Status

ROHS3 Compliant

REACH SVHC

No SVHC

Lead Free

Lead Free
