Lifecycle Status

ACTIVE (Last Updated: 7 months ago)

Factory Lead Time

16 Weeks

Package / Case

16-VFLGA

Surface Mount

YES

Number of Pins

16

Usage Level

Industrial grade

Operating Temperature

-40°C~85°C TA

Packaging

Cut Tape (CT)

Part Status

Active

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

16

ECCN Code

EAR99

Type

Digital

HTS Code

8542.39.00.01

Voltage - Supply

1.71V~3.6V

Terminal Position

BOTTOM

Terminal Form

BUTT

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Supply Voltage

2.4V

Terminal Pitch

0.4mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

L2G2

Output Type

SPI

Supply Voltage-Max (Vsup)

3.6V

Supply Voltage-Min (Vsup)

1.71V

Operating Supply Current

3.8mA

Axis

X (Pitch), Y (Roll)

Features

Adjustable Bandwidth, Selectable Scale, Sleep Mode, Temperature Sensor

Range °/s

±100, 200

Sensitivity (LSB/(°/s))

131 ~ 262

Length

2.3mm

Height Seated (Max)

0.7mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
