Factory Lead Time

8 Weeks

Mounting Type

Cable, Free Hanging

Package / Case

Metal

Shell Material

Zinc Alloy

Insert Material

Thermoplastic

Backshell Material, Plating

Zinc, Chrome

Contact Finish Mating

Gold

Contact Materials

Copper Alloy

Insulation Materials

Plastic

Voltage Rated

125VAC

Packaging

Bulk

Series

Q-G® AAA

Published

2007

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Termination

Solder Cup

ECCN Code

EAR99

Connector Type

Receptacle, Male Pins

Number of Positions

3

Color

Black

Applications

Audio, Industrial, Instrumentation, Medical

Gender

Male

Fastening Type

Latch Lock

DIN Conformance

NO

IEC Conformance

NO

Option

GENERAL PURPOSE

Current Rating (Amps)

15A

Orientation

Keyed

Shielding

Shielded

Military Standard

NO

Shell Finish

Chrome

Shell Size - Insert

XLR

Number of Ports

1

Number of Poles

3

Cable Opening

0.100 ~ 0.220 (2.54mm ~ 5.59mm)

Current Rating (Max)

15A

Features

Backshell, Cable Clamp, Ground, Strain Relief

REACH SVHC

not_compliant

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
