Factory Lead Time

10 Weeks

Mounting Type

Surface Mount

Package / Case

19-PowerFLGA Module

Surface Mount

YES

Operating Temperature

-40°C~125°C

Packaging

Tape & Reel (TR)

Series

Enpirion®

Size / Dimension

0.15Lx0.15W x 0.07 H 3.8mmx3.8mmx1.9mm

Part Status

Active

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

19

Type

Non-Isolated PoL Module

Applications

ITE (Commercial)

Additional Feature

ADJUSTABLE OUTPUT RANGE= (0.75-6.36 VOLT)

Terminal Position

BOTTOM

Terminal Form

NO LEAD

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Number of Outputs

1

Efficiency

96%

Voltage - Input (Max)

6.6V

Voltage - Input (Min)

2.7V

Input Voltage-Nom

5V

Control Mode

VOLTAGE-MODE

Control Technique

PULSE WIDTH MODULATION

Switcher Configuration

BUCK

Switching Frequency-Max

2200kHz

Features

OCP, OTP, SCP, UVLO

Length

3.75mm

Width

3.75mm

RoHS Status

RoHS Compliant
