Factory Lead Time

8 Weeks

Mount

Cable, Free Hanging

Mounting Type

Free Hanging (In-Line)

Package / Case

Metal

Shell Material

Stainless Steel

Housing Material

Zinc

Weight

45.359237g

Insert Material

Polyester

Body Material

Metal, Zinc

Backshell Material, Plating

Zinc, Nickel

Contact Finish Mating

Silver

Contact Materials

Brass

Voltage Rated

125VAC

Packaging

Bulk

Series

Q-G® A

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Termination

Solder Cup

Connector Type

Plug, Female Sockets

Number of Positions

4

Applications

Audio, Instrumentation

Gender

Female

Additional Feature

POLARIZING

Fastening Type

Latch Lock

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Option

GENERAL PURPOSE

Orientation

Keyed

Current Rating

10A

Shell Size - Insert

XLR

Plating

Nickel

Number of Ports

1

Number of Poles

4

Cable Opening

0.210 ~ 0.300 (5.33mm ~ 7.62mm)

Features

Backshell, Cable Clamp, Ground, Strain Relief

Height

25.4mm

Length

82.55mm

Width

25.4mm

REACH SVHC

Unknown

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
