Factory Lead Time

12 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

12-SIP Module, 6 Leads

Number of Pins

6

Operating Temperature

-20°C~80°C With Derating

Packaging

Bulk

Series

BP5048

Published

2010

Size / Dimension

1.38Lx0.36W x 0.87 H 35.0mmx9.2mmx22.0mm

JESD-609 Code

e2

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

6

ECCN Code

EAR99

Type

Enclosed

Terminal Finish

Tin/Copper (Sn/Cu)

Applications

ITE (Commercial)

Power (Watts)

3W

Max Power Dissipation

3W

Terminal Position

SINGLE

Peak Reflow Temperature (Cel)

260

Number of Functions

1

Terminal Pitch

2.54mm

Time@Peak Reflow Temperature-Max (s)

10

Pin Count

12

Number of Outputs

1

Efficiency

75%

Output Voltage

15V

Max Output Current

200mA

Input Voltage-Nom

311V

Trim/Adjustable Output

NO

Max Supply Voltage

390V

Min Supply Voltage

180V

Output Current

200mA

Output Power

3.1W

Total Power Output-Max

3.22W

Max Supply Voltage (AC)

276V

Line Regulation

50mV

Min Supply Voltage (AC)

127V

Height

22.098mm

Radiation Hardening

No

RoHS Status

ROHS3 Compliant

Lead Free

Contains Lead
