Factory Lead Time

15 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

10-SIP Module, 5 Leads

Number of Pins

5

Operating Temperature

-25°C~80°C With Derating

Packaging

Bulk

Series

BP5041

Published

2010

Size / Dimension

1.28Lx0.45W x 0.76 H 32.5mmx11.5mmx19.3mm

JESD-609 Code

e2

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

5

ECCN Code

EAR99

Type

Enclosed

Terminal Finish

Tin/Copper (Sn/Cu)

Applications

ITE (Commercial)

Power (Watts)

1W

Max Power Dissipation

1W

Terminal Position

SINGLE

Peak Reflow Temperature (Cel)

260

Number of Functions

1

Time@Peak Reflow Temperature-Max (s)

10

Pin Count

10

Number of Outputs

1

Efficiency

62%

Output Voltage

12V

Max Output Current

100mA

Input Voltage-Nom

282V

Trim/Adjustable Output

NO

Output Current

100mA

Output Power

1.2W

Max Supply Voltage (AC)

276V

Line Regulation

20mV

Load Regulation

50mV

Min Supply Voltage (AC)

160V

Height

19.304mm

Radiation Hardening

No

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
