Factory Lead Time

12 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

9-SIP Module, 5 Leads

Operating Temperature

-20°C~80°C With Derating

Packaging

Bulk

Series

BP5065

Published

2002

Size / Dimension

1.03Lx0.28W x 0.60 H 26.1mmx7.2mmx15.2mm

JESD-609 Code

e2

Pbfree Code

yes

Part Status

Not For New Designs

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

5

ECCN Code

EAR99

Type

Enclosed

Terminal Finish

TIN COPPER

Applications

ITE (Commercial)

Power (Watts)

1W

Max Power Dissipation

1W

Terminal Position

SINGLE

Peak Reflow Temperature (Cel)

260

Number of Functions

1

Terminal Pitch

2.54mm

Time@Peak Reflow Temperature-Max (s)

10

JESD-30 Code

R-XSMA-T5

Number of Outputs

1

Qualification Status

Not Qualified

Efficiency

68%

Output Voltage

-13V

Max Output Current

90mA

Input Voltage-Nom

-141V

Trim/Adjustable Output

NO

Line Regulation

50mV

Load Regulation

70mV

Height

15.24mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
