Factory Lead Time

10 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

14-SIP Module, 10 Leads

Number of Pins

14

Operating Temperature

-20°C~85°C With Derating

Published

2010

Size / Dimension

1.52Lx0.44W x 0.91 H 38.5mmx11.2mmx23.2mm

JESD-609 Code

e3/e2

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

10

ECCN Code

EAR99

Type

Enclosed

Terminal Finish

TIN/TIN COPPER

Applications

ITE (Commercial)

Power (Watts)

12W

Max Power Dissipation

12W

Terminal Position

SINGLE

Peak Reflow Temperature (Cel)

260

Number of Functions

1

Terminal Pitch

2.54mm

Time@Peak Reflow Temperature-Max (s)

10

Number of Outputs

1

Qualification Status

Not Qualified

Efficiency

83%

Output Voltage

-12V

Max Output Current

1A

Input Voltage-Nom

-141V

Trim/Adjustable Output

NO

Line Regulation

3mV

Load Regulation

13mV

Features

Adjustable Output

Height

23.114mm

RoHS Status

ROHS3 Compliant
