Factory Lead Time

10 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

8-SIP Module, 5 Leads

Number of Pins

8

Operating Temperature

-25°C~80°C With Derating

Published

2010

Size / Dimension

0.94Lx0.40W x 1.00 H 24.0mmx10.1mmx25.5mm

JESD-609 Code

e2

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

6

ECCN Code

EAR99

Type

Enclosed

Terminal Finish

Tin/Copper (Sn/Cu)

Applications

ITE (Commercial)

Power (Watts)

12W

Max Power Dissipation

12W

Terminal Position

SINGLE

Peak Reflow Temperature (Cel)

260

Number of Functions

1

Supply Voltage

12V

Terminal Pitch

2.54mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-XSMA-T6

Number of Outputs

1

Qualification Status

Not Qualified

Output Voltage

12V

Max Output Current

1A

Input Voltage-Nom

141V

Trim/Adjustable Output

NO

Line Regulation

10mV

Load Regulation

58mV

Height

25.4mm

RoHS Status

ROHS3 Compliant
