Mounting Type

Surface Mount

Package / Case

8-SOIC (0.173, 4.40mm Width)

Surface Mount

YES

Driver Configuration

High-Side or Low-Side

Logic voltage-VIL, VIH

0.8V 2.6V

Operating Temperature

-40°C~125°C TA

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

8

ECCN Code

EAR99

Voltage - Supply

10V~20V

Terminal Position

DUAL

Terminal Form

GULL WING

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Supply Voltage

15V

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-PDSO-G8

Input Type

Inverting

Rise / Fall Time (Typ)

30ns 30ns

Interface IC Type

HALF BRIDGE BASED MOSFET DRIVER

Channel Type

Independent

Number of Drivers

2

Turn On Time

0.37 µs

Gate Type

IGBT, N-Channel MOSFET

High Side Driver

YES

Turn Off Time

0.37 µs

High Side Voltage - Max (Bootstrap)

600V

Length

5mm

Height Seated (Max)

1.71mm

Width

4.4mm

RoHS Status

ROHS3 Compliant
