number of connections

2

Open-end side panels

Yes

Insulation Materials

PA

Flame retardant grade, in line with UL94

V0

Insulating material group

I

RoHS

No excessive harmful substances

Anti-finger touch

Passed the test

Temperature rise test

≤45 K

Voltage drop

≤3.2mV

Rotational Pull Test

Passed the test

Fixing support

Passed the test

Mechanical strength

Passed the test

Ambient temperature (storage/transportation)

-25℃~60℃

Relative humidity (storage/transport)

25%~75%

Ambient temperature (operation)

-40 °C ~ 105 °C（depending on derating curve）

Rated surge voltage

8KV

Tightening torque

1.54N.m

Screw type

Slotted screw

Conductor cross section flexible (ferrule with plastic sleeve)

0.5-10mm²

Conductor cross section flexible (ferrule without plastic sleeve)

0.5-10mm²

Conductor cross section flexible

0.5~10mm²

Conductor cross section solid

0.5~10mm²

Conductor cross section solid AWG

20~6

Strip length

10~12mm

NS 35/15 Height

51mm

NS 35/7,5 Height

43.5mm

End plate width

1.5mm

standard test

IEC60947-7-2

Number of rows

1

screw thread

M4

Connection method

screw connection

length

44.95mm

Height

42mm

width

10mm

REACh SVHC

Lead 7439-92-1
