number of connections

2

Open-end side panels

Yes

Insulation Materials

PA

Flame retardant grade, in line with UL94

V0

Insulating material group

I

standard test

IEC60947-7-1

End plate width

4mm

NS 35/7,5 Height

52.6mm

NS 35/15 Height

60.1mm

Strip length

16~17mm

Conductor cross section solid AWG

24~6

Conductor cross section solid

0.2~16mm²

Conductor cross section flexible

0.2~16mm²

Rated voltage (III / 3)

800V

Rated current(III/3)

76A

Rated surge voltage

8KV

Ambient temperature (operation)

-40 °C ~ 105 °C（depending on derating curve）

Relative humidity (storage/transport)

25%~75%

Ambient temperature (storage/transportation)

-25℃~60℃

Mechanical strength

Passed the test

Fixing support

Passed the test

Rotational Pull Test

Passed the test

Voltage drop

≤3.2mV

Temperature rise test

≤45 K

Anti-finger touch

Passed the test

RoHS

No excessive harmful substances

Number of rows

1

Rated current

65A

Connection method

spring-cage connection

Rated voltage

600V

width

12mm

Height

49.85mm

length

58.5mm

REACh SVHC

Lead 7439-92-1
