Number of pins

12

Connector cross section

0.14 - 1mm²

RoHS-compliant

Yes

Content

5pc(s)

Total no. of pins

12

Industrial packaging

Yes

Leading contact (PE)

No

Connections

Soldering,Crimp

Manufacturer part #

73002722

Connectable conductor cross section solid-core

0.14 - 1

Rated surge voltage

1.5

Inflammability class of insulation material according to with UL94

V0

Overvoltage category

III

With wire protection

Yes

Pollution degree

3

Connectable conductor cross section multi-wired

0.14 - 1

Contact insert without contacts

No

Material contact

Brass

Material of contact surface

Gold

Diameter plug-in contact

1

Material connector insert

Thermoplastic

Connectable conductor cross section fine-strand without cable end sleeve

0.14 - 1

Rated current In

7

Ambient temperature

-25 - 125

Type of electric connection

Soldering connection

Connectable conductor cross section fine-strand with cable end sleeve

0.14 - 1

With protective conductor

No

Rohs Code

Yes

Manufacturer Part Number

73002722

Manufacturer

Lapp Group

Part Life Cycle Code

Active

Ihs Manufacturer

LAPP GROUP PVT LTD

Risk Rank

5.68

Connector type

Socket

Type

E-part, right-hand

Connector Support Type

CONNECTOR ACCESSORY

Test current

7A

Rated voltage

150V

Features

Right-hand

REACH SVHC

compliant
