Number of pins

12

Connector cross section

0.08 - 0.56mm²

Manufacturer part #

44420124

Connections

Crimp

Leading contact (PE)

No

Industrial packaging

Yes

Total no. of pins

12

Content

5pc(s)

With protective conductor

No

Connectable conductor cross section fine-strand with cable end sleeve

0.08 - 0.56

Type of electric connection

Crimp connection

Ambient temperature

-25 - 125

Rated current In

4

Connectable conductor cross section fine-strand without cable end sleeve

0.08 - 0.56

Material connector insert

Thermoplastic

Diameter plug-in contact

1

Material of contact surface

Gold

Material contact

Brass

Contact insert without contacts

Yes

Connectable conductor cross section multi-wired

0.08 - 0.56

Pollution degree

3

With wire protection

Yes

Overvoltage category

III

Inflammability class of insulation material according to with UL94

V0

Rated surge voltage

1.5

Connectable conductor cross section solid-core

0.08 - 0.56

Connector type

Plug

Type

P-part, left-hand

Test current

4A

Rated voltage

100V

Features

Left-hand
