Bend radius (no. of ODs for flexible installation)

15

Bend radius (no. of ODs for fixed installation)

4

Cable Types

ÖLFLEX® CLASSIC 100 YELLOW

Content

Sold per metre

Cross section

3 G 1.50 mm²

Factory colour

Yellow

Cross section (each core)

1.50mm²

Halogen-free

No

Insulation Materials

PVC

Cable features

Flexible,High flexural strength

Manufacturer part #

10400-1

Nominal voltage

750V

Outside Ø

8.10mm

Max. length sold by the metre

300m

Nominal voltage U0

450V

Max. temperature range (fixed installation)

+80°C

Min. temperature range (fixed installation)

-40°C

Max. temperature range (flexible installation)

+70°C

Min. temperature range (flexible installation)

-5°C

Number-coded

No

No. of leads

3G

Package

No

Core layout

Finely stranded according to VDE 0295, Class 5/IEC 60228 Cl.5

Certification marks

In accordance with: IEC 60227-5 HD 21.5 S3 · VDE 0281 Part 5 · HD 21.13 S1 · VDE 0281 Part 13

RoHS-compliant

Yes

Sold per metre

Yes

Type

ÖLFLEX® CLASSIC 100

Insulation

PVC

Test voltage

4000V
