Bend radius (no. of ODs for fixed installation)

12

Content

Sold per metre

Cross section

2 x 0.22mm²

Factory colour

Green,White

Cross section (each core)

0.22mm²

Halogen-free

No

Insulation Materials

PVC

Manufacturer part #

162051-1

Material (details)

Nickel - Chrome -Nickel

Outside Ø

4.60mm

Max. length sold by the metre

500m

No. of leads

2x

Package

No

Core layout

7 x 0.20 mm

Cable Types

NI-CR/NITYPK/2X0.22/IECPVC-PVC

Certification marks

Referring to: boundry deviation according to DIN 42714 of class 2

RoHS-compliant

Yes

Sold per metre

Yes

Type

NI-CR/NI TYPE K/2X0.22/IEC PVC-PVC

Temperature range

-5 - +70°C

Bend radius

(without metal braiding) 12 x wire -Ø<br>(with metal braiding) 15 x wire-Ø
