Material

Polyamide

Internal thread

PG16

Factory colour

Black (RAL 9005)

Min. temperature

-20°C

Max. temperature

+100°C

Halogen-free

No

Content

1pc(s)

RoHS-compliant

Yes

Manufacturer part #

53019240

Material (details)

Polyamide, fibreglass reinforced

Maximum Operating Temperature

+100°C

Minimum Operating Temperature

-20°C

Surface protection

Untreated

Glass-fibre reinforced

Yes

Thread length

6

Explosion-tested version

No

With locknut

No

Thread type

PG

Nominal thread size metric/PG

16

Wrench width

30

Material quality

Polyamide (PA)

Bend radius protection/trumpet flare

No

Shock resistant

No

Model

Straight

Rohs Code

Yes

Manufacturer Part Number

53019240

Manufacturer

Lapp Group

Part Life Cycle Code

Active

Ihs Manufacturer

LAPP GROUP PVT LTD

Risk Rank

2.22

ECCN Code

EAR99

Type

SKINTOP® GMP-GL PG16

Color

Black

Reach Compliance Code

compliant

Connector Support Type

CONNECTOR ACCESSORY

Thread Size

PG16

Temperature range

-20 - +100°C

IP Rating

IP68
