Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

8-UFBGA, FCBGA

SwitchingFrequency

1MHz

Operating Temperature

-40°C~85°C TA

Packaging

Tape & Reel (TR)

Published

2006

JESD-609 Code

e3

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

8

ECCN Code

EAR99

Type

DC DC Regulator

Terminal Finish

MATTE TIN

Applications

Backlight

Additional Feature

CAN BE CONFIGURED IN CURRENT MODE

Terminal Position

BOTTOM

Terminal Form

BALL

Peak Reflow Temperature (Cel)

260

Number of Functions

1

Terminal Pitch

0.5mm

Time@Peak Reflow Temperature-Max (s)

40

Base Part Number

NCP5010

Pin Count

8

JESD-30 Code

S-PBGA-B8

Number of Outputs

1

Qualification Status

Not Qualified

Output Voltage

20V

Input Voltage-Nom

3.6V

Output Power

500mW

Input Voltage (Min)

2.7V

Topology

Step-Up (Boost)

Control Mode

VOLTAGE-MODE

Output Current-Max

0.56A

Input Voltage (Max)

5.5V

Control Technique

PULSE WIDTH MODULATION

Internal Switch(s)

Yes

Dimming

Analog

Voltage - Supply (Max)

5.5V

Voltage - Supply (Min)

2.7V

Height Seated (Max)

0.66mm

RoHS Status

RoHS Compliant
