Mount

Socket

Package / Case

Dust Cover

Number of Pins

8

Weight

35 g

CoilResistance

605 Ω

Contact Materials

Silver

Voltage Rating (AC)

250 V

Voltage Rating (DC)

24 V

Enclosure

Plastic

Manufacturer Part Number

RU2S-D-D24

Manufacturer

IDEC

Mounting

Plug In

Relay Construction

Non-Latching

Pick-up Voltage (Max)

19.2VDC

Product Depth (mm)

21(mm)

LED Indicator

Yes

Operating Temp Range

-55C to 60C

Mounting Styles

Socket

Voltage Rating (VDC)

30(V)

Dropout Volt

2.4VDC

Seal

Unsealed

Maximum Power Rating

300W/2.5KVA

Rad Hardened

No

Contact Rating

10A

Factory Pack QuantityFactory Pack Quantity

1

Maximum Switching Current

10 A

Brand

IDEC

RoHS

Details

Series

RU

Termination

Solder

Type

Universal

Max Operating Temperature

60 °C

Min Operating Temperature

-55 °C

Subcategory

Relays

Current Rating

10 A

Pin Count

8

Termination Style

Solder Lug

Approval Agency

CE, CSA, TUV, cULus

Operating Supply Voltage

800 mV

Contact Resistance

50 MΩ

Max Voltage Rating (AC)

250 V

Max Current Rating

10 A

Throw Configuration

DPDT

Max Voltage Rating (DC)

30 V

Contact Current Rating

10(A)

Contact Termination

Plug In

Contact Form

2 Form C

Terminal Type

Blade Plug-In

Product Type

Plug-In Relay

Operate Time

20 ms

Coil Voltage

24 VDC

Coil Type

Non-Latching

Switching Voltage

250 VAC, 30 VDC

Coil Current

41.7 mA

Power Consumption

1 W

Coil Voltage (DC)

24 V

Contact Arrangement

DPDT

Contact Configuration

DPDT

Product

Power Relays

Input Voltage

24VDC

Coil Suppression Diode

Yes

Product Category

General Purpose Relays

Contacts

DPDT

Voltage Rating (VAC)

250(V)

Product Length (mm)

27.5(mm)

Width

21 mm

Height

35 mm

Length

27.5 mm

Product Height (mm)

41.6(mm)

RoHS Status

RoHS Compliant
