Lifecycle Status

ACTIVE (Last Updated: 2 days ago)

Factory Lead Time

7 Weeks

Contact Plating

Tin

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

6-SOIC (0.173, 4.40mm Width), 5 Leads

Number of Pins

5

Weight

181.33333mg

Number of Elements

1

Operating Temperature

-40°C~110°C

Packaging

Tube

Published

2010

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

ECCN Code

EAR99

Additional Feature

CMOS COMPATIBLE, UL RECOGNIZED

Max Power Dissipation

40mW

Voltage - Supply

3V~5.5V

Supply Voltage

5.5V

Voltage - Isolation

3750Vrms

Output Voltage

5V

Output Type

Push-Pull, Totem Pole

Configuration

SINGLE

Number of Channels

1

Power Dissipation

70mW

Output Current

10mA

Voltage - Forward (Vf) (Typ)

1.35V

Propagation Delay

55 ns

Input Type

DC

Turn On Delay Time

55 ns

Optoelectronic Device Type

LOGIC IC OUTPUT OPTOCOUPLER

Forward Current

20mA

Response Time

5.5e-8 ns

Data Rate

20Mbps

Direction

Unidirectional

Output Current per Channel

10mA

Rise Time

5.8ns

Fall Time (Typ)

5.3 ns

Rise / Fall Time (Typ)

5.8ns 5.3ns

Reverse Breakdown Voltage

5V

Max Input Current

20mA

Input Current

16mA

Propagation Delay tpLH / tpHL (Max)

55ns, 55ns

Common Mode Transient Immunity (Min)

20kV/μs

Inputs - Side 1/Side 2

1/0

Reverse Voltage (DC)

5V

REACH SVHC

No SVHC

Radiation Hardening

No

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
