Mounting Type

Surface Mount

Package / Case

48-TFSOP (0.724, 18.40mm Width)

Surface Mount

YES

Number of Pins

48

Memory Types

Non-Volatile

Operating Temperature

-40°C~85°C TA

Packaging

Tray

Published

1998

JESD-609 Code

e6

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

48

Terminal Finish

TIN BISMUTH

Voltage - Supply

2.7V~3.6V

Terminal Position

DUAL

Peak Reflow Temperature (Cel)

260

Number of Functions

1

Supply Voltage

3V

Terminal Pitch

0.5mm

Reach Compliance Code

unknown

Frequency

70GHz

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Qualification Status

Not Qualified

Supply Voltage-Max (Vsup)

3.6V

Supply Voltage-Min (Vsup)

2.7V

Memory Size

16Mb 1M x 16

Operating Mode

ASYNCHRONOUS

Memory Format

FLASH

Memory Interface

Parallel

Data Bus Width

16b

Organization

1MX16

Memory Width

16

Write Cycle Time - Word, Page

70ns

Access Time (Max)

70 ns

Programming Voltage

1.8V

Length

18.4mm

Height Seated (Max)

1.2mm

RoHS Status

RoHS Compliant

Lead Free

Lead Free
