Factory Lead Time

8 Weeks

Mounting Type

Surface Mount

Package / Case

2-SMD, No Lead

Surface Mount

YES

Memory Types

Non-Volatile

Operating Temperature

-40°C~85°C TC

Packaging

Tape & Reel (TR)

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

2

Voltage - Supply

1.7V~3.6V

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Terminal Pitch

2mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

AT21CS01

JESD-30 Code

R-PSSO-N2

Memory Size

1Kb 128 x 8

Number of Ports

1

Operating Mode

SYNCHRONOUS

Clock Frequency

125kHz

Memory Format

EEPROM

Memory Interface

I2C, Single Wire

Organization

128X8

Memory Width

8

Write Cycle Time - Word, Page

5ms

Standby Current-Max

0.0000015A

Memory Density

1024 bit

Parallel/Serial

SERIAL

Programming Voltage

3.6V

Serial Bus Type

1-WIRE

Endurance

100000 Write/Erase Cycles

Write Cycle Time-Max (tWC)

5ms

Data Retention Time-Min

100

Write Protection

SOFTWARE

Voltage - Supply (Max)

3.6V

Voltage - Supply (Min)

1.7V

Page Size

8words

Reverse Pinout

NO

Length

5mm

Height Seated (Max)

0.4mm

Width

3.5mm

RoHS Status

ROHS3 Compliant
