Mount

Surface Mount

Package / Case

SOIC

Number of Pins

14

Current - Supply (Nom)

2mA

Power Dissipation (Max)

1W

Usage Level

Automotive grade

Packaging

Tape and Reel

Published

2007

JESD-609 Code

e0

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

14

ECCN Code

EAR99

Terminal Finish

Tin/Lead (Sn/Pb)

Max Operating Temperature

105°C

Min Operating Temperature

-40°C

Terminal Position

DUAL

Terminal Form

GULL WING

Peak Reflow Temperature (Cel)

240

Number of Functions

4

Supply Voltage

5V

Terminal Pitch

1.27mm

Reach Compliance Code

not_compliant

Time@Peak Reflow Temperature-Max (s)

30

Pin Count

14

Current - Supply (Max)

2mA

Qualification Status

Not Qualified

Output Type

OPEN-COLLECTOR

Power Supplies

5V

Temperature Grade

AUTOMOTIVE

Number of Channels

4

Max Supply Voltage

36V

Min Supply Voltage

3V

Power Dissipation

1W

Current - Output

16mA

Response Time

1.3 μs

Amplifier Type

COMPARATOR

Current - Input Bias

250nA

Output Current per Channel

16mA

Input Offset Voltage (Vos)

7mV

Voltage Gain

100dB

Average Bias Current-Max (IIB)

0.5μA

Max Dual Supply Voltage

18V

Min Dual Supply Voltage

1.5V

Bias Current-Max (IIB) @25C

0.25μA

Screening Level

AEC-Q100

Length

8.65mm

Height Seated (Max)

1.75mm

Width

3.9mm

RoHS Status

Non-RoHS Compliant

Lead Free

Contains Lead
