Mount

Surface Mount

Package / Case

SOIC

Number of Pins

8

Current - Supply (Nom)

1mA

Published

1992

JESD-609 Code

e4

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

8

ECCN Code

EAR99

Terminal Finish

Nickel/Palladium/Gold (Ni/Pd/Au)

Max Operating Temperature

125°C

Min Operating Temperature

-55°C

Terminal Position

DUAL

Terminal Form

GULL WING

Peak Reflow Temperature (Cel)

260

Number of Functions

2

Supply Voltage

5V

Time@Peak Reflow Temperature-Max (s)

30

Pin Count

8

Current - Supply (Max)

1mA

Output Type

OPEN-COLLECTOR

Power Supplies

5V

Temperature Grade

MILITARY

Number of Channels

2

Max Supply Voltage

36V

Min Supply Voltage

2V

Response Time

1.3 μs

Amplifier Type

COMPARATOR

Current - Input Bias

250nA

Input Offset Voltage (Vos)

5mV

Voltage Gain

106.02dB

Average Bias Current-Max (IIB)

0.4μA

Max Dual Supply Voltage

18V

Min Dual Supply Voltage

1V

Length

4.9mm

Height Seated (Max)

1.75mm

Width

3.9mm

Radiation Hardening

No

RoHS Status

RoHS Compliant
