Factory Lead Time

13 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

6-UFDFN Exposed Pad

Number of Pins

6

Diode Element Material

SILICON

Breakdown Voltage / V

13.5V

Number of Elements

2

Reverse Stand-off Voltage

4V

Operating Temperature

-40°C~125°C TJ

Packaging

Tape & Reel (TR)

Series

Automotive, AEC-Q101, SP1255P, SPA®

Published

2013

JESD-609 Code

e3

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

6

Termination

SMD/SMT

ECCN Code

EAR99

Type

Steering (Rail to Rail)

Terminal Finish

Matte Tin (Sn)

Applications

Automotive, USB OTG

Additional Feature

ULTRA LOW CAPACITANCE

HTS Code

8541.10.00.50

Capacitance

500mF

Terminal Position

DUAL

Terminal Form

NO LEAD

Peak Reflow Temperature (Cel)

260

Time@Peak Reflow Temperature-Max (s)

40

Working Voltage

12V

Polarity

UNIDIRECTIONAL

Configuration

COMPLEX

Number of Channels

3

Power Line Protection

Yes

Voltage - Breakdown (Min)

4.5V

Current - Peak Pulse (10/1000μs)

2A 8/20μs

Clamping Voltage

8.5V

Voltage - Reverse Standoff (Typ)

4V Max

Peak Pulse Current

2A

Max Surge Current

100A

JEDEC-95 Code

MO-229

Capacitance @ Frequency

0.5pF @ 1MHz

RoHS Status

ROHS3 Compliant
