Factory Lead Time

11 Weeks

Mounting Type

PCB, Surface Mount

Package / Case

SMD/SMT

Number of Pins

16

Voltage - Input (Nom)

24V

Power - Output (Max)

2W

Power Dissipation (Max)

2W

Voltage-Output 1

15V

Published

2011

Number of Terminations

16

ECCN Code

EAR99

Max Operating Temperature

85°C

Min Operating Temperature

-40°C

Power Rating

2W

Terminal Position

DUAL

Terminal Form

GULL WING

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Depth

23.86mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Number of Outputs

1

Efficiency

80 %

Voltage - Isolation

1.5kV

Operating Supply Voltage

24V

Temperature Grade

OTHER

Trim/Adjustable Output

NO

Analog IC - Other Type

DC-DC REGULATED POWER SUPPLY MODULE

Current - Output (Max)

200mA

Current - Output

133mA

Voltage - Output

15V

Min Input Voltage

18V

Max Input Voltage

36V

Power - Output

2W

Nominal Output Voltage

15V

Max Input Voltage (DC)

26.4V

Min Input Voltage (DC)

21.6V

Load Regulation-Max(%)

1%

Features

SCP

Height

7.874mm

Length

23.876mm

Width

13.716mm

REACH SVHC

No SVHC

RoHS Status

RoHS Compliant
