Package / Case

TQFP

Surface Mount

YES

Number of I/Os

48

Operating Temperature (Max.)

85°C

Operating Temperature (Min.)

-40°C

Published

2012

JESD-609 Code

e3

Part Status

Discontinued

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

64

ECCN Code

3A001.A.3

Terminal Finish

Matte Tin (Sn) - annealed

HTS Code

8542.31.00.01

Terminal Position

QUAD

Terminal Form

GULL WING

Peak Reflow Temperature (Cel)

260

Terminal Pitch

0.5mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Pin Count

64

JESD-30 Code

S-PQFP-G64

Qualification Status

Not Qualified

Supply Voltage-Max (Vsup)

3.6V

Temperature Grade

INDUSTRIAL

Supply Voltage-Min (Vsup)

2.7V

Speed

66 MHz

uPs/uCs/Peripheral ICs Type

MICROCONTROLLER, RISC

Clock Frequency

66MHz

Bit Size

32

Has ADC

NO

DMA Channels

NO

PWM Channels

YES

DAC Channels

NO

Address Bus Width

20

External Data Bus Width

16

ROM Programmability

FLASH

Length

20mm

Height Seated (Max)

1.6mm

Width

20mm

RoHS Status

RoHS Compliant
