Surface Mount

NO

Number of Pins

5

Operating Temperature (Max.)

125°C

Operating Temperature (Min.)

-40°C

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Discontinued

Number of Terminations

5

ECCN Code

EAR99

Terminal Finish

Tin (Sn)

HTS Code

8542.39.00.01

Terminal Position

SINGLE

Terminal Form

THROUGH-HOLE

Peak Reflow Temperature (Cel)

260

Number of Functions

1

Terminal Pitch

1.7mm

Time@Peak Reflow Temperature-Max (s)

40

JESD-30 Code

R-PSFM-T5

Number of Outputs

2

Qualification Status

Not Qualified

Output Voltage 1

12V

Input Voltage (Min)

6V

Input Voltage (Max)

26V

Dropout Voltage1-Nom

0.4V

Output Voltage1-Max

12.6V

Output Voltage1-Min

11.4V

Regulator Type

FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR

Voltage Tolerance-Max

5%

Output Current1-Max

0.4A

Dropout Voltage1-Max

0.6V

Operating Temperature TJ-Max

150°C

Input Voltage Absolute-Max

26V

Adjustability

FIXED

Load Regulation-Max(%)

0.08%

Output Voltage 2

5V

Line Regulation-Max (%/V)

0.08%

Operating Temperature TJ-Min

-40°C

Output Voltage2-Max

5.1V

Output Voltage2-Min

4.9V

Output Current2-Max

0.2A

Dropout Voltage2-Max

0.6V

RoHS Status

RoHS Compliant

Lead Free

Lead Free
