Package / Case

TO-220-5

Surface Mount

NO

Number of Pins

5

Operating Temperature (Max)

150°C

Operating Temperature (Min)

-40°C

JESD-609 Code

e3

Pbfree Code

yes

Number of Terminations

5

ECCN Code

EAR99

Terminal Finish

Tin (Sn)

Terminal Position

SINGLE

Terminal Form

THROUGH-HOLE

Peak Reflow Temperature (Cel)

260

Number of Functions

1

Terminal Pitch

1.7mm

Time@Peak Reflow Temperature-Max (s)

40

JESD-30 Code

R-PSFM-T5

Number of Outputs

2

Qualification Status

Not Qualified

Output Type

Fixed

Current - Output

400mA

Voltage - Output

12V

Output Voltage 1

12V

Max Input Voltage

60V

Dropout Voltage1-Nom

0.4V

Voltage Tolerance-Max

5%

Load Regulation-Max(%)

0.08%

Output Voltage 2

5V

Line Regulation-Max (%/V)

0.08%

RoHS Status

RoHS Compliant

Lead Free

Lead Free
