Mount

Surface Mount

Package / Case

SMD/SMT

Actuator Material

POLYCARBONATE

Center Contact Plating

GOLD

Center Contact Material

BRASS

End Contact Material

BRASS

End Contact Plating

GOLD

ElectricalLife

1000000 Cycle(s)

Insulation Materials

POLYETHERSULPHONE

Operating Temperature (Max.)

85°C

Operating Temperature (Min.)

-25°C

Packaging

Tape & Reel (TR)

Published

2001

JESD-609 Code

e3

Pbfree Code

yes

ECCN Code

EAR99

Terminal Finish

Matte Tin (Sn)

Additional Feature

HOLE FOR LED, W/ LEGEND

Body Length or Diameter

18.3896mm

Body Breadth

18.3896 mm

Actuator Type

PUSHBUTTON

Switch Function

SPST

Contact Resistance

0.05mOhm

Insulation Resistance

100000000Ohm

Contact Current(DC)-Max

0.05A

Contact Voltage(DC)-Max

24V

Termination Type

SOLDER

Switch Type

PUSHBUTTON SWITCH

Contact Timing

BREAK-BEFORE-MAKE

Contact (DC) Max Rating R Load

0.05A@24VDC

PCB Hole Count

6

Contact Function

OFF-ON-(OFF)

Switch Action

MOMENTARY

Contact (DC) Max Power Rating R Load

0.36VA@24VDC

Body Height

8.509mm

Length - Termination

0.126 inch

RoHS Status

Non-RoHS Compliant
