Factory Lead Time

8 Weeks

Contact Plating

Lead, Tin

Mount

Surface Mount

Package / Case

BGA

Number of Pins

313

Frequency(Max)

33MHz

Published

2004

JESD-609 Code

e0

Pbfree Code

no

Part Status

Active

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

313

ECCN Code

EAR99

Terminal Finish

Tin/Lead (Sn/Pb)

Max Operating Temperature

85°C

Min Operating Temperature

-40°C

HTS Code

8542.39.00.01

Terminal Position

BOTTOM

Terminal Form

BALL

Peak Reflow Temperature (Cel)

225

Supply Voltage

5V

Terminal Pitch

2.54mm

Time@Peak Reflow Temperature-Max (s)

20

Pin Count

313

Operating Supply Voltage

5V

Power Supplies

5V

Temperature Grade

INDUSTRIAL

uPs/uCs/Peripheral ICs Type

BUS CONTROLLER, VME

Data Rate

560 Mbps

Bus Compatibility

PCI

Data Transfer Rate-Max

70 MBps

Length

35mm

Height Seated (Max)

3.5mm

Width

35mm

Thickness

2.3mm

Radiation Hardening

No

RoHS Status

RoHS Compliant

Lead Free

Contains Lead
