Mount

Surface Mount

Package / Case

PLCC

Number of Pins

84

Memory Types

ROMless

Number of I/Os

64

RAM(byte)

488

ROM(word)

0

Packaging

Bulk

Published

1996

JESD-609 Code

e0

Part Status

Discontinued

Number of Terminations

84

Terminal Finish

Tin/Lead (Sn/Pb)

Max Operating Temperature

70°C

Min Operating Temperature

0°C

Terminal Position

QUAD

Terminal Form

J BEND

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Supply Voltage

5V

Frequency

16MHz

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Pin Count

84

Qualification Status

Not Qualified

Operating Supply Voltage

5V

Power Supplies

5V

Temperature Grade

INDUSTRIAL

Max Supply Voltage

5.5V

Min Supply Voltage

4.5V

Oscillator Type

External

RAM Size

488B

uPs/uCs/Peripheral ICs Type

MICROCONTROLLER

Peripherals

PWM, WDT

Supply Current-Max

70mA

Bit Size

16

Access Time

16 μs

Has ADC

YES

DMA Channels

NO

PWM Channels

YES

DAC Channels

NO

Number of Timers/Counters

2

Address Bus Width

16

CPU Family

8096

Boundary Scan

NO

Low Power Mode

YES

External Data Bus Width

16

Format

FIXED POINT

Integrated Cache

NO

RAM (words)

488

Number of External Interrupts

2

On Chip Data RAM Width

8

Height Seated (Max)

4.83mm

RoHS Status

Non-RoHS Compliant
